Contact Us| Model | CS20 | CS24 | CS28 | CS32 |
| Magnification | 20X | 24X | 28X | 32X |
| Standard Deviation For 1KM Double-Run Leveling | ±2.5mm | ±2.0mm | ±1.5mm | ±1.0mm |
| Objective Aperture | 36mm | 36mm | 40mm | 40mm |
| Setting Accuracy | ±2.5″ | ±2.0″ | ±0.5″ | ±0.3″ |
| Field Of View | 1°30' | |||
| Shortest Focuing Distance | 0.3m | |||
| Compensator Type | Magnetic-Damping | |||
| Working Range Of Compensator | ±15′ | |||
| Sensitivity Of Circular Vial | 8'/2mm | |||
| Horizontal Outer Circle | 1° or /1gon | |||
| Standard Accessories | Adjusting Pin, Dessoccatoimg Agemt, Hex Key, Plumb Bob, User Manual | |||
