Contact Us| Model | DB24 | DB28 | DB32 |
| Magnification | 24X | 28X | 32X |
| Standard Deviation For 1KM Double-Run Leveling | 2.0mm (0.008ft) | 2.0mm (0.008ft) | 2.0mm (0.008ft) |
| Objective Aperture | 32mm | 36mm | 36mm |
| Setting Accuracy | ±0.3″ | ±0.5″ | ±0.4″ |
| Resolving Power | 4.0″ | 3.5″ | 3.5″ |
| Field Of View | 1°25' | 1°25' | 1°25' |
| Shortest Focuing Distance | 0.3m | ||
| Compensator Type | Magnetic-Damping | ||
| Automatic Compensator Range | ±15' | ±15' | ±15' |
| Sensitivity Of Circular Vial | 10'/2mm | ||
| Horizontal Outer Circle | 1° or /1gon | ||
| Standard Accessories | Adjusting Pin, Dessoccatoimg Agemt, Hex Key, Plumb Bob, User Manual | ||
