RL03

Specification:
*Accuracy: Horizontal 30 arc seconds(+/-1.5mm/10m)
*Self leveling range: ±5°
*Operation rang: Dia. 500m (with detector)
*Laser class:Class II.
*Remote c

Mail box
  • info@katsens.com

  • katsens@vip.163.com

Specification:

*Accuracy: Horizontal 30 arc seconds(+/-1.5mm/10m)

*Self leveling range: ±5°

*Operation rang: Dia. 500m (with detector)

*Laser class:Class II.

*Remote control: Approx.20 m

*Rotate head speed: 0; 300; 600 r. p. m.

*Operation temperature: -20oC ~ +50oC (-4°F~+122°F)

*Power supply: DC 4. 8-6V (both 4*AA NI-MH battery and alkaline battery are available )

*Working time: Approx. 30hr.

*Dust and water protection: IP 54

*Dimension: 190(L)*145(W)*166(H)mm
