Contact UsSpecification:
Level system: Electronic sensor fast leveling.
Accuracy: 20 arc seconds(+/-1mm/10m)
Self leveling range: ±5°
Operation rang: 500m with detector(Diameter)
Five head speeds: 0; 60; 120; 300; 600 R.P.M
Four scan widths:10°; 45°; 90°; 180°
FRE203(Red beam):Wavelength:635nm Class II FRE203G(Green beam):Wavelength:515nm-520nm Class 3R
Green beam is X5 times brighter than red one.
Remote control;Available working distance:20 m
Operation temperature: -20oC ~ +50oC (-4°F~+122°F)
Power supply: DC 4. 8-6V (4*sub-C NI-MH battery)
Continiuance working time: Approx. 50hr.
Waterproof and dustproof: IP 54
Dimension: 160(L) X 160(W)X 185(H)mm
Weight: 2.5kg
