Contact Us| Telescope | |||||||||
| Clear objective aperture | 45mm | ||||||||
| Magnification | 30X | ||||||||
| Image | Erect | ||||||||
| Angle of field of view | 1°30' | ||||||||
| Shortest stadla | 1.5m | ||||||||
| Distance Measurment | |||||||||
| Method of measurment | Raster incremental/Absolutely code | ||||||||
| Reflector-less Accuracy Measuiring Range | 200m | ||||||||
| Reflector Accuracy Measuring Range | 5.5km | ||||||||
| Measurment Accuracy | (Reflector-less) ±(5mm+3ppm·D) | ||||||||
| Precise measurment mode:1mm | |||||||||
| Measurment speed | Repeat swift measurment: about 0.9sec first time about 2.5sec | ||||||||
| Measuring angle system | |||||||||
| Least reading | 10"/5"/1" | ||||||||
| Standard deviation | 2" | ||||||||
| Measrument time | 0.1" | ||||||||
| Compesnstaor | ±3' | ||||||||
| Laser/Optical plummet | ±1mm | ||||||||
| Communication Standard | |||||||||
| Memory points | 50000 Points | ||||||||
| Communication Standard | RS-232C | ||||||||
| Battery | |||||||||
| Battery Type | RechargeableNI-NH battery | ||||||||
| Vottage | DC7.2V | ||||||||
| Capacitance | 4000mAH/3000mAH | ||||||||
| Temperature Range | |||||||||
| Memory | -40°C~+60°C | ||||||||
| Working | -20°C~+55°C | ||||||||
| Waterproof | IP54 | ||||||||
