Contact Us| Telescope | |||||||||
| Length of Telescope | 156mm | ||||||||
| Image | Erect | ||||||||
| Clear Objective Aperture | 45mm | ||||||||
| Magnification | 30X | ||||||||
| Angle of Field of View | 1°30' | ||||||||
| Resolving Power | 3.5" | ||||||||
| Shortest Focuing Distance | 1.3m | ||||||||
| Electronic Angle Measurment | |||||||||
| Detection system | Absolutely code | ||||||||
| Reading Pattem | Horizontal circle: across Vertical circle:across | ||||||||
| Display mode | Double Face | ||||||||
| Minimum reading | 1"/5"/10"/20" | ||||||||
| Accuracy | 2" | ||||||||
| Compenstaor | |||||||||
| Electronic incline senor | Vertical angle compensation | ||||||||
| Arrange | ±3' | ||||||||
| Communication interface | |||||||||
| Communication standard | RS232C | ||||||||
| EDM input port | No supplied | ||||||||
| Date Output port | Supplied | ||||||||
| Optical plummet | |||||||||
| Base type | Detachable base | ||||||||
| Image | Erect | ||||||||
| Magnification | 4X | ||||||||
| Field of view | 5° | ||||||||
| Accuracy | 0.5mm/1.5mm | ||||||||
| Level Sensitivity | |||||||||
| Plate Level | 30"/2mm | ||||||||
| Circular Level | 8"/2mm | ||||||||
| Others | |||||||||
| Power supply | NI-H Chargeable battery box | ||||||||
| Net weight | 4.8kg | ||||||||
